Topcon
Topcon LS-B20 Machine Receiver
Topcon LS-B20 Machine Magnetic Mounted Laser Receiver
£645.00 +VAT
In stock
- Free next-day UK delivery on orders over £200 ex VAT
- 5-year manufacturer warranty & support
- 30-day no-quibble returns
Need advice? Talk to a survey specialist
Call 01522 697777 or email our team — we use this kit on site every day and can help you choose the right configuration.
Product overview
Applications
• Grade Checking
• Site Work
• Foundation & Exterior
• Utility & Underground
• Machine Control
The LS-B20 laser receiver provides a versatile, low-cost indicator solution for grade checking and machine control grade applications such as site work, trench and pipe alignment, trench excavation, vertical alignment, levelling footings, and forms. This tiny and lightweight item includes an integrated magnetic mount for quick installation and mobility between machines. the LS-B20 with an optional Holder-6 clamp, is excellent for manual grade checking also.
Features and Benefits
• Machine control and grade-checking capability • 4 on-grade zone selections (LED); coarse to fine grade for machine control
• zero-set function
• Magnetic mount: use anywhere • Easy switch to exterior or interior works • LED indicators: Bright red and green • Operating time: Up to 100 Hours
Technical Data
• Detecting Angle Range: 270°
• Detecting Range: 120mm
• Battery life: Up to 100 hours with alkaline batteries
• Batteries: 3 AA dry-cell alkaline
• Low Battery Indicator: Yes
• Mountings: Built-in magnet mount, optional grade rod clamp attachment
• Operating temperature: -20 °C to +50 °C (-4 °F to +122 °F)
• Buttons: 4 (power, mode, buzzer and 0-set)
• Beeper: dual tone; loud and light
• Auto-shut off: After 30 minutes
• Mode to turn off LED: Yes
• Dimensions: 115 x 40 x 180 mm
• Weight: 500 g
• Waterproof: IP66
• Warranty: 12 Months
