Suparule CHM600E Cable Height Meter
Measure cable sag and height differences as well as overhead clearance of conductors with the Suparule CHM600E Cable Height Meter.
£560.00 +VAT
In stock
- Free next-day UK delivery on orders over £200 ex VAT
- 5-year manufacturer warranty & support
- 30-day no-quibble returns
Need advice? Talk to a survey specialist
Call 01522 697777 or email our team — we use this kit on site every day and can help you choose the right configuration.
Product overview
Measure cable sag and height differences as well as overhead clearance of conductors with the Suparule CHM600E Cable Height Meter. The CHM600E is capable of measuring up to six wires and up to 23m height measurement.
A great alternative to telescopic measuring rods, this cable height meter is ideal for use within utilities industries such as telecoms.
The CHM600 works by emitting short bursts of sound, which the instrument’s microprocessor can then use to calculate the elapsed time for the sound to be reflected from the cable back to the instrument. The results are then displayed in metric or imperial units.
Range:
25mm Cable 3-23m
12mm Cable 3-15m
Features
0.5kg Weight
Compact Size
Auto Power off
50,000 Measurement Battery Life
0.5% ± 2 digits Accuracy
Six Wire Measurement
